Centurion SDO5 Smart+ T10 Garage Door Sectional Belt Kit

The SDO5 SMΔRT+ brings SMΔRT + remote access to your garage door motor, built for garage doors where reliable daily access and SMΔRTer control matter. Control your garage door from anywhere in the world.

The SDO5 SMΔRT+ T10 is ideal for:

• Standard domestic garage doors
• Tip-up or sectional garage door configurations

SDO5 SMΔRT+ Features

• Model options: T10 and T12 variants (positioned for different domestic door requirements)
• Drive system: Belt drive for quiet garage operation
• Safety: Built-in collision sensing with auto-reverse; adjustable sensitivity
• 24V drive system: mains powered, with T10 suited to standard home garage doors, and T12 delivering extra drive power for larger setups
• The backup Battery fits in the motor housing.
• Connectivity: BLE and Wi-Fi
• Accessories integration: Two configurable input/output channels and one input
• Receiver capacity: 30 x 4-Button Transmitters

For Centurion Accredited Installers Click this link : Myinstaller

Additional information pertaining to the T10 SDO5 SMART+ Garage Motor:
1. Can operate off a solar supply, please consult for assistance.
2. Add-on Battery Backup kit sold separately. Contact your local stockist for assistance.
3. Only applicable if battery backup is installed.
4. Speed varies with load.
5. Requires Infrared Safety Beams to be fitted.

Warnings and Limitations on the T10 SDO5 SMART+ Garage Motor:
1. All installations must be done by a suitable qualified technician
2. Under no circumstances may any of the components be modified.

WHAT’S IN THE BOX:
1 x SDO5 T10 SMART+ head unit with power supply and batteries
1 x Header Bracket
1 x Drive Rail Hanger
1 x Bent Towing Arm
2 x Centurion Nova 4 Button Remotes
1 x Mounting Kit

1 x Quick Guide

1 x 3.18meter Extrusion Arm
