Olarm Link

Olarm LINK is smart control and sensing device allowing users to control a wide range of peripherals such as gate motors, garage motors, boom gates, water pumps, and more.



Monitor & Control More Remotely

DIN Rail mountable (plastic DIN rail included)

6x Protected general purpose I/O Ports which can either be used as inputs or open drain outputs.

Analog sensor port for use with either 4-20mA or 0-14V sensors.

2 high current relays allow for control of AC loads or high current DC loads.

2 tamper switches.

RGB status indication light.

Supported Olarm communicators allowing up to 8 Olarm LINK to be connected to one communicator.

Connects Via an Olarm PRO, Olarm PRO 4G or Olarm MAX communicator.





Dimensions : 87x70x37 mm



Included in the box

1x Olarm LINK

1x 1.5m communications cable

1x Plastic DIN rail

1x DIN rail clip

2x screws

2x wall plugs
